Standard and custom aluminum U channel extrusions from 9.5mm to 101.6mm base width. 17 standard sizes in 1050, 1070, 3103 and 6060 alloys. For electronics, electromechanical automation, furnishing, construction and domestic applications. Custom profiles upon request.
Standard and custom U-shaped extrusions in 1050, 1070, 3103 and 6060 alloys. All dimensions in millimeters. Theoretical weight in kg/m.
| Part Code | Size B x H (mm) | Thickness S (mm) | Weight (kg/m) |
|---|---|---|---|
| CNJL95X95X0.8 | 9.5 x 9.5 | 0.8 | 0.058 |
| CNJL127X127X0.8 | 12.7 x 12.7 | 0.8 | 0.079 |
| CNGY0015 | 14.66 x 19.05 | 2 | 0.263 |
| CNGY0016 | 17.26 x 19.05 | 2 | 0.278 |
| CNCL09.05X19.05X1.2 | 19.05 x 19.05 | 1.2 | 0.178 |
| CNGY0167 | 25 x 25 | 1.6 | 0.313 |
| CNJL254X127X0.8 | 25.4 x 12.7 | 0.8 | 0.107 |
| CNGY0169 | 25.4 x 15.88 | 1.58 | 0.233 |
| CNGY0019 | 25.4 x 25.4 | 3.1 | 0.588 |
| CNUC31.75X16.5X2.0 | 31.75 x 16.5 | 2 | 0.332 |
| CNUC32X25.4X2.5 | 32 x 25.4 | 2.5 | 0.531 |
| CNJL38X18X17 | 38 x 18 | 1.7 | 0.335 |
| CNGY0017 | 24.74 x 38.1 | 2.8 | 0.734 |
| CNUC44.1X21.0X2.0 | 44.1 x 21 | 2 | 0.448 |
| CNJL4445X127X0.8 | 44.45 x 12.7 | 0.8 | 0.148 |
| CNGY0018 | 25.4 x 50.8 | 3.1 | 1.014 |
| CNJL1016X1905X1 | 101.6 x 19.05 | 1 | 0.374 |
17 standard sizes available. Custom U channel profiles available upon request.
