Aluminum round tubes and solid bar from 12.7mm to 63.2mm diameter. 16 standard sizes (15 round hollow sections + 1 solid bar) in 1050, 1070, 3103 and 6060 alloys. Ideal for mechanical, electromechanical, construction and furnishing applications. Custom sizes on request.
Round hollow sections and one solid bar in 1050, 1070, 3103 and 6060 alloys. All dimensions in millimeters. Theoretical weight in kg/m.
| Part Code | Diameter D (mm) | Thickness S (mm) | Weight (kg/m) |
|---|---|---|---|
| CNYG12.7 | 12.7 | - | 0.346 |
| CNGY0129 | 16 | 1.2 | 0.151 |
| CNYG19.85X3.18 | 19.85 | 3.18 | 0.454 |
| CNYG19.95X1.8 | 19.95 | 1.8 | 0.28 |
| CNYG20X2.0 | 20 | 2 | 0.309 |
| CNYG20.9X1.65 | 20.9 | 1.65 | 0.272 |
| CNYG23.13X1.55 | 23.13 | 1.55 | 0.286 |
| CNYG24X1.55 | 24 | 1.55 | 0.298 |
| CNYG24X1.6 | 24 | 1.6 | 0.307 |
| CNYG2516 | 25 | 1.6 | 0.321 |
| CNYG27.5X1.35 | 27.5 | 1.35 | 0.303 |
| CNYG34X3.1 | 34 | 3.1 | 0.822 |
| CNGY0134 | 48.4 | 4 | 1.512 |
| CNYG50X3.0 | 50 | 3 | 1.209 |
| CNYG50X10.0 | 50 | 10 | 3.431 |
| CNYG63.2X3.0 | 63.2 | 3 | 1.549 |
16 sizes available (15 round tubes + 1 solid bar). Custom sizes upon request.
