Standard aluminum square tube extrusions from 15.88mm to 152.4mm. 85 sizes available in 6060 & 6063 alloys with wall thickness from 0.8mm to 6.35mm. Ideal for construction, furnishing, mechanical and electromechanical assemblies. Contact us for custom sizes, cutting and surface finishing.
All dimensions in millimeters. Theoretical weight in kg/m. Alloy, temper, finish and MOQ are confirmed at quotation.
| Part Code | Size L x H (mm) | Thickness S (mm) | Weight (kg/m) |
|---|---|---|---|
| CNFG15.88X15.88X0.8 | 15.88 x 15.88 | 0.8 | 0.131 |
| CNFS01003 | 15.88 x 15.88 | 1.27 | 0.202 |
| CNLG207 | 16 x 16 | 1.2 | 0.193 |
| CNFG17X0.9 | 17 x 17 | 0.9 | 0.156 |
| CNLG-KF16 | 19 x 19 | 1.2 | 0.23 |
| CNLG-KF71A | 19 x 19 | 1.45 | 0.276 |
| CNFG191916 | 19 x 19 | 1.6 | 0.302 |
| CNFG252515 | 25 x 25 | 1.5 | 0.385 |
| CNFG25X25X2.0 | 25 x 25 | 2 | 0.502 |
| CNFS01012 | 25.3 x 25.3 | 1.5 | 0.388 |
| CNFG252508 | 25.4 x 25.4 | 0.8 | 0.213 |
| CNFG252510 | 25.4 x 25.4 | 1 | 0.265 |
| CNFG25425416 | 25.4 x 25.4 | 1.55 | 0.401 |
| CNFG254X18 | 25.4 x 25.4 | 1.8 | 0.463 |
| CNFG31.75X31.75X1.2 | 31.75 x 31.75 | 1.2 | 0.4 |
| CNFG31.75X31.75X2.4 | 31.75 x 31.75 | 2.4 | 0.769 |
| CNFG32*32 | 32 x 32 | 1 | 0.337 |
| CNFG323203 | 32 x 32 | 3 | 0.929 |
| CNFG38X19 | 38 x 38 | 1.9 | 0.749 |
| CNFG38X191 | 38 x 38 | 1.91 | 0.753 |
| CNFG38.1X38.1X1.45 | 38.1 x 38.1 | 1.45 | 0.568 |
| CNFG38.1X38.1X1.8 | 38.1 x 38.1 | 1.8 | 0.741 |
| CNFG38.1X38.1X2.0 | 38.1 x 38.1 | 2 | 0.788 |
| CNFG38138123 | 38.1 x 38.1 | 2.3 | 0.893 |
| CNFG38.1X38.1X2.41 | 38.1 x 38.1 | 2.41 | 0.939 |
| CNLG-KF65 | 38.1 x 38.1 | 3.08 | 1.174 |
| CNFG76250830-2 | 38.1 x 38.1 | 3.2 | 1.651 |
| CNGY0127 | 40 x 40 | 2 | 0.805 |
| CNGY0128 | 40 x 40 | 3 | 1.182 |
| CNGP3762B | 44.45 x 44.45 | 0.9 | 0.423 |
| CNGP3762C | 44.45 x 44.45 | 1.1 | 0.515 |
| CNGP3762A | 44.45 x 44.45 | 1.12 | 0.524 |
| CNFG454515 | 44.45 x 44.45 | 1.5 | 0.704 |
| CNGP3782 | 44.45 x 44.45 | 1.5 | 0.699 |
| CNFG44.45X44.45X2.0 | 44.45 x 44.45 | 2 | 0.927 |
| CNGP3782A | 44.5 x 44.5 | 1.4 | 0.654 |
| CNFG44.5X44.5X2.4 | 44.5 x 44.5 | 2.4 | 1.102 |
| CNFG505016 | 50 x 50 | 1.6 | 0.846 |
| CNFG505018 | 50 x 50 | 1.8 | 0.904 |
| CNGY0126 | 50 x 50 | 2 | 0.994 |
| CNFG50X3 | 50 x 50 | 3 | 1.54 |
| CNGY0124 | 50 x 50 | 3 | 1.466 |
| CNFG5065X192 | 50.65 x 50.65 | 1.92 | 1.022 |
| CNFG50.8X50.8X1.45 | 50.8 x 50.8 | 1.45 | 0.769 |
| CNFG50.8X50.8X1.5 | 50.8 x 50.8 | 1.5 | 0.808 |
| CNFG508X191 | 50.8 x 50.8 | 1.91 | 1.008 |
| CNFG50.8X50.8X2.0 | 50.8 x 50.8 | 2 | 1.066 |
| CNFG50.8X50.8X2.23 | 50.8 x 50.8 | 2.23 | 1.183 |
| CNFG508X239 | 50.8 x 50.8 | 2.39 | 1.263 |
| CNLG201 | 50.8 x 50.8 | 2.4 | 1.259 |
| CNFG50.8X50.8X3.0 | 50.8 x 50.8 | 3 | 1.453 |
| CNLG208 | 50.8 x 50.8 | 3 | 1.554 |
| CNFG50.8X50.8X3.08 | 50.8 x 50.8 | 3.08 | 1.59 |
| CNFG50.8X50.8X3.15 | 50.8 x 50.8 | 3.15 | 1.639 |
| CNFG57.1X57.1X2.4 | 57.15 x 57.15 | 2.4 | 1.435 |
| CNFG63.5X63.5X1.45 | 63.5 x 63.5 | 1.45 | 0.971 |
| CNLG-KF39 | 63.5 x 63.5 | 1.45 | 0.971 |
| CNFG635X2 | 63.5 x 63.5 | 2 | 1.334 |
| CNLG202 | 63.5 x 63.5 | 2 | 1.328 |
| CNFG63.5X63.5X2.4 | 63.5 x 63.5 | 2.4 | 1.601 |
| CNFG63.5X2.41 | 63.5 x 63.5 | 2.41 | 1.598 |
| CNFG63.5X63.5X3.08 | 63.5 x 63.5 | 3.08 | 2.017 |
| CNLG-KF07 | 63.5 x 63.5 | 3.08 | 2.017 |
| CNFG635X31 | 63.5 x 63.5 | 3.1 | 2.045 |
| CNFG63.5X63.5X3.9 | 63.5 x 63.5 | 3.9 | 2.518 |
| CNFG656503 | 65 x 65 | 3 | 1.982 |
| CNFG69.5X69.5X3.1 | 69.5 x 69.5 | 3.1 | 2.248 |
| CNFS01014 | 76 x 76 | 2.25 | 1.808 |
| CNLG-KF71 | 76.05 x 76.05 | 3.08 | 2.437 |
| CNFG762X2 | 76.2 x 76.2 | 2 | 1.621 |
| CNLG-KF69 | 76.2 x 76.2 | 2.9 | 2.317 |
| CNFG762X3 | 76.2 x 76.2 | 3 | 2.398 |
| CNLG-KF73 | 76.2 x 76.2 | 3.9 | 3.507 |
| CNLG-KF79 | 76.2 x 76.2 | 3.9 | 3.075 |
| CNFG90X90X2.0 | 90 x 90 | 2 | 1.913 |
| CNFG100X100X3.0 | 100 x 100 | 3 | 3.178 |
| CNFG101X2 | 101 x 101 | 2 | 2.162 |
| CNFG101*101 | 101.6 x 101.6 | 1.8 | 1.954 |
| CNFG1016X24 | 101.6 x 101.6 | 2.4 | 2.6 |
| CNFG101.6X101.6X3.0 | 101.6 x 101.6 | 3 | 3.181 |
| CNFG1016X31 | 101.6 x 101.6 | 3.1 | 3.334 |
| CNFG1016X315 | 101.6 x 101.6 | 3.15 | 3.383 |
| CNFG101.6X101.6X6.35 | 101.6 x 101.6 | 6.35 | 6.605 |
| CNFG150X150X3.0 | 150 x 150 | 3 | 4.806 |
| CNFS01030 | 152.4 x 152.4 | 3.08 | 4.955 |
85 standard sizes available. Custom sizes upon request.
